Page #55 background imageLoading...
Page #55 background image
e30bu183.12
U
W
V
-XD4.1
-XD11.1
-XDL.1
1
2
4
3
5
Illustration 26: Split Shipment Electrical Connections (D10h Sine-wave Cabinet)
Additional terminal connections
Thermal protection wiring harness to drive cabinet
DC-link harness to fan supply in drive cabinet
Cabinet heater supply harness to drive cabinet
Motor cables (U/V/W) to motor terminals (U/V/W) in
drive cabinet
AQ357954340588en-000201 / 130R0881 | 55Danfoss A/S © 2020.09
Electrical Installation
VLT® Refrigeration Drive FC 103
Operating Guide
