Table 52: Option C1 Terminal Connections for VLT® Advanced Cascade Controller MCO 102
Option card terminal
Corresponding terminal within the control compartment
X67.1
XDF.21
X67.2
XDF.22
X67.3
XDF.23
X67.4
XDF.24
X67.5
XDF.25
X67.6
XDF.26
X67.7
XDF.27
X67.8
XDF.28
X67.9
XDF.29
X67.10
XDF.30
X67.11
XDF.31
X67.12
XDF.32
X66.1
XDF.1
X66.2
XDF.2
X66.3
XDF.3
X66.4
XDF.4
X66.5
XDF.5
X66.6
XDF.6
X66.7
XDF.7
X66.8
XDF.8
X66.9
XDF.9
X66.10
XDF.10
X66.11
XDF.11
X66.12
XDF.12
X66.13
XDF.13
X66.14
XDF.14
X58.1
XDF.15
X58.2
XDF.16
Table 53: Option D Terminal Connections
Option card terminal
Corresponding terminal within the control compartment
35
XD2.28
AQ357954340588en-000201 / 130R088174 | Danfoss A/S © 2020.09
Electrical Installation
VLT® Refrigeration Drive FC 103
Operating Guide
