13-52 SL Controller Action
Array [20]
Option: Function:
[25] Qstop Issues a quick stop command to the
frequency converter.
[26] DC Brake Issues a DC stop command to the
frequency converter.
[27] Coast The frequency converter coasts
immediately. All stop commands
including the coast command stop the
SLC.
[28] Freeze output Freezes the output frequency of the
frequency converter.
[29] Start timer 0 Starts timer 0, see parameter 13-20 SL
Controller Timer for further description.
[30] Start timer 1 Starts timer 1, see parameter 13-20 SL
Controller Timer for further description.
[31] Start timer 2 Starts timer 2, see parameter 13-20 SL
Controller Timer for further description.
[32] Set digital out A
low
Any output with digital output 1
selected is low (o).
[33] Set digital out B
low
Any output with digital output 2
selected is low (o).
[34] Set digital out C
low
Any output with digital output 3
selected is low (o).
[35] Set digital out D
low
Any output with digital output 4
selected is low (o).
[38] Set digital out A
high
Any output with digital output 1
selected is high (closed).
[39] Set digital out B
high
Any output with digital output 2
selected is high (closed).
[40] Set digital out C
high
Any output with digital output 3
selected is high (closed).
[41] Set digital out D
high
Any output with digital output 4
selected is high (closed).
[60] Reset Counter A Resets counter A to 0.
[61] Reset Counter B Resets counter B to 0.
[70] Start Timer 3 Starts timer 3, see parameter 13-20 SL
Controller Timer for further description.
[71] Start Timer 4 Starts timer 4, see parameter 13-20 SL
Controller Timer for further description.
[72] Start Timer 5 Starts timer 5, see parameter 13-20 SL
Controller Timer for further description.
[73] Start Timer 6 Starts timer 6, see parameter 13-20 SL
Controller Timer for further description.
[74] Start Timer 7 Starts timer 7, see parameter 13-20 SL
Controller Timer for further description.
[100] Reset Alarm Reset the alarm.
