Danfoss VLT HVAC Basic Drive FC 101

13-44 Logic Rule Boolean 3
Array [6]
Option: Function:
[83] Broken Belt
3.9.6 13-5* States
13-51 SL Controller Event
Array [20]
Option: Function:
Select the boolean input (true or
false) to dene the smart logic
controller event.
See parameter 13-02 Stop Event for
further descriptions of options and
their functions.
[0] * False
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
13-51 SL Controller Event
Array [20]
Option: Function:
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken Belt
13-52 SL Controller Action
Array [20]
Option: Function:
Select the action corresponding to the
SLC event. Actions are executed when
the corresponding event (dened in
parameter 13-51 SL Controller Event) is
evaluated as true. The following actions
are available for selection:
[100] ResetAlarm
[0] * Disabled
[1] No action
[2] Select set-up 1 Changes the active set-up
(parameter 0-10 Active Set-up) to set-up
1.
[3] Select set-up 2 Changes the active set-up
(parameter 0-10 Active Set-up) to set-up
2.
[10] Select preset ref
0
Selects preset reference 0.
[11] Select preset ref
1
Selects preset reference 1.
[12] Select preset ref
2
Selects preset reference 2.
[13] Select preset ref
3
Selects preset reference 3.
[14] Select preset ref
4
Selects preset reference 4.
[15] Select preset ref
5
Selects preset reference 5.
[16] Select preset ref
6
Selects preset reference 6.
[17] Select preset ref
7
Selects preset reference 7. If the active
preset reference is changed, it merges
with other preset reference commands
coming from either the digital inputs or
via a eldbus.
[18] Select ramp 1 Selects ramp 1.
[19] Select ramp 2 Selects ramp 2.
[22] Run Issues a start command to the
frequency converter.
[23] Run reverse Issues a start reverse command to the
frequency converter.
[24] Stop Issues a stop command to the
frequency converter.
Parameters Programming Guide
MG18B502 Danfoss A/S © 04/2018 All rights reserved. 73
3 3
