Bit
Output/Relay
22
Option C relay 7 output terminal
23
Option C relay 8 output terminal
21–31
Reserved for future terminals
Parameter 5-93 Pulse Out #27 Bus Control
Table 391: Parameter 5-93 Pulse Out #27 Bus Control
5-93 Pulse Out #27 Bus Control
Default value: 0%
Parameter type: Range, 0 - 100%
Setup: All setups
Conversion index: -2
Data type: N2
Change during operation: True
Set the output frequency transferred to output terminal 27 when the terminal is configured as [45] Bus Controlled in parameter 5-60
Terminal 27 Pulse Output Variable.
Parameter 5-94 Pulse Out #27 Timeout Preset
Table 392: Parameter 5-94 Pulse Out #27 Timeout Preset
5-94 Pulse Out #27 Timeout Preset
Default value: 0%
Parameter type: Range, 0 - 100%
Setup: 1 setup
Conversion index: -2
Data type: Uint16
Change during operation: True
Set the output frequency transferred to output terminal 27 when the terminal is configured as [48] Bus Ctrl Timeout in parameter
5-60 Terminal 27 Pulse Output Variable and a timeout is detected.
Parameter 5-95 Pulse Out #29 Bus Control
Table 393: Parameter 5-95 Pulse Out #29 Bus Control
5-95 Pulse Out #29 Bus Control
Default value: 0%
Parameter type: Range, 0 - 100%
Setup: All setups
Conversion index: -2
Data type: N2
Change during operation: True
Set the output frequency transferred to output terminal 29 when the terminal is configured as [45] Bus Controlled in parameter 5-63
Terminal 29 Pulse Output Variable.
Parameter 5-96 Pulse Out #29 Timeout Preset
Table 394: Parameter 5-96 Pulse Out #29 Timeout Preset
5-96 Pulse Out #29 Timeout Preset
Default value: 0%
Parameter type: Range, 0 - 100%
Setup: 1 setup
Conversion index: -2
Data type: Uint16
Change during operation: True
Set the output frequency transferred to output terminal 29 when the terminal is configured as [48] Bus Ctrl Timeout in parameter
5-63 Terminal 29 Pulse Output Variable and a timeout is detected.
Parameter 5-97 Pulse Out #X30/6 Bus Control
Table 395: Parameter 5-97 Pulse Out #30/6 Bus Control
5-97 Pulse Out #30/6 Bus Control
Default value: 0%
Parameter type: Range, 0 - 100%
Setup: All setups
Conversion index: -2
Data type: N2
Change during operation: True
AU275636650261en-000101 / 130R0334230 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide

Danfoss VLT HVAC Drive FC 102 Specifications

General

Enclosure	IP20, IP21, IP55
Ambient Temperature Range	-10°C to +40°C
Storage Temperature Range	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Communication Protocols	Modbus RTU, BACnet, Profibus
Certifications	CE, UL, cUL
Control Principle	PWM
Cooling Method	Forced air cooling
Input Voltage	200-240V, 380-480V, 525-600V
Control Modes	sensorless vector control, closed loop vector control
