Danfoss VLT HVAC Drive FC 102 Programming Guide

Option
Name
Description
[19]
X30/4 DI status
[20]
CTW timeout toggle inverse
[21]
Thermal warning
[22]
Execution distance extended
N O T I C E
This option is only available with software version 48.9X.
Indicates that the offset execution distance (set in parameter 17-95 Offset Execution Dis-
tance) has been extended due to speed/ramp limitation.
[29]
Protection mode
[30]
Brake fault (IGBT)
[40]
Out of ref range
[49]
Derate active
[54]
Running
[59]
On reference
[60]
Comparator 0
[61]
Comparator 1
[62]
Comparator 2
[63]
Comparator 3
[64]
Comparator 4
[65]
Comparator 5
[66]
Comparator 6
[67]
Comparator 7
[68]
Comparator 8
[69]
Comparator 9
[70]
Logic rule 0
[71]
Logic rule 1
[72]
Logic rule 2
[73]
Logic rule 3
[74]
Logic rule 4
[75]
Logic rule 5
[76]
Logic rule 6
[77]
Logic rule 7
[78]
Logic rule 8
AU275636650261en-000101 / 130R0334 | 277Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide

Danfoss VLT HVAC Drive FC 102 Specifications

General

Enclosure	IP20, IP21, IP55
Ambient Temperature Range	-10°C to +40°C
Storage Temperature Range	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Communication Protocols	Modbus RTU, BACnet, Profibus
Certifications	CE, UL, cUL
Control Principle	PWM
Cooling Method	Forced air cooling
Input Voltage	200-240V, 380-480V, 525-600V
Control Modes	sensorless vector control, closed loop vector control
