Option
Name
Description
[1788]
Master home position
[3310]
Sync factor master
[3311]
Sync factor slave
[3401]
PCD 1 write to MCO
[3402]
PCD 2 write to MCO
[3403]
PCD 3 write to MCO
[3404]
PCD 4 write to MCO
[3405]
PCD 5 write to MCO
[3406]
PCD 6 write to MCO
[3407]
PCD 7 write to MCO
[3408]
PCD 8 write to MCO
[3409]
PCD 9 write to MCO
[3410]
PCD 10 write to MCO
[3644]
Terminal X49/7 bus control
[3654]
Terminal X49/9 bus control
[3664]
Terminal X49/11 bus control
[4520]
Type
Parameter 9-16 PCD Read Configuration
Table 545: Parameter 9-16 PCD Read Configuration
9-16 PCD Read Configuration
Default value: Size related
Parameter type: Option, Array 156
Setup: All setups
Conversion index: –
Data type: Uint16
Change during operation: True
Select the parameters to be assigned to PCD 3–10 of the telegrams. The number of available PCDs depends on the telegram type.
Values in PCD 3–10 are written to the selected parameters as data. For standard PROFIBUS telegrams, see parameter 9-22 Telegram
Selection.
Option
Name
Description
[-]
None
[15]
Readout: actual setup
[1397]
Alert alarm word
[1398]
Alert warning word
[1399]
Alert status word
[1472]
Legacy alarm word
[1473]
Legacy warning word
AU275636650261en-000101 / 130R0334306 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide

Danfoss VLT HVAC Drive FC 102 Specifications

General

Enclosure	IP20, IP21, IP55
Ambient Temperature Range	-10°C to +40°C
Storage Temperature Range	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Communication Protocols	Modbus RTU, BACnet, Profibus
Certifications	CE, UL, cUL
Control Principle	PWM
Cooling Method	Forced air cooling
Input Voltage	200-240V, 380-480V, 525-600V
Control Modes	sensorless vector control, closed loop vector control
