Danfoss VLT HVAC Drive FC 102 Programming Guide

Option
Name
Description
[483]
Power limit generator mode
[491]
Positive speed limit [RPM]
[492]
Positive speed limit [Hz]
[493]
Negative speed limit [RPM]
[494]
Negative speed limit [Hz]
[495]
Positive torque limit
[496]
Negative torque limit
[553]
Term. 29 high ref./feedb. value
[558]
Term. 33 high ref./feedb. value
[590]
Digital & relay bus control
[593]
Pulse out #27 bus control
[595]
Pulse out #29 bus control
[597]
Pulse out #30/6 bus control
[615]
Terminal 53 high ref./feedb. value
[625]
Terminal 54 high ref./feedb. value
[653]
Term 42 output bus ctrl
[663]
Terminal X30/8 bus control
[673]
Terminal X45/1 bus control
[683]
Terminal X45/3 bus control
[702]
Speed PID proportional gain
[703]
Speed PID integral time
[708]
Speed PID feed forward factor
[748]
PCD feed forward
[890]
Bus jog 1 speed
[891]
Bus jog 2 speed
[1680]
Fieldbus CTW 1
[1681]
Fieldbus sync. REF
[1682]
Fieldbus REF 1
[1683]
Fieldbus pos. REF
[1685]
FC port CTW 1
[1686]
FC port REF 1
[1688]
Fieldbus torque FF.
AU275636650261en-000101 / 130R0334 | 353Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide

Danfoss VLT HVAC Drive FC 102 Specifications

General

Enclosure	IP20, IP21, IP55
Ambient Temperature Range	-10°C to +40°C
Storage Temperature Range	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Communication Protocols	Modbus RTU, BACnet, Profibus
Certifications	CE, UL, cUL
Control Principle	PWM
Cooling Method	Forced air cooling
Input Voltage	200-240V, 380-480V, 525-600V
Control Modes	sensorless vector control, closed loop vector control
