Danfoss VLT HVAC Drive FC 102 Programming Guide

Option
Name
Description
[3]
Set-up 3
[4]
Set-up 4
[9]
Multi Set-up
Remote setup selections using digital inputs and the serial communication port. This setup used the
settings from parameter 0-12 This Set-up Linked to. Stop the drive before making changes to open-loop
and closed-loop functions.
Parameter 0-11 Edit Set-up
Table 12: Parameter 0-11 Edit Set-up
0-11 Edit Set-up
Default value: [1] Set-up 1
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select the setup to be edited (programmed) during operation, either the active setup or 1 of the inactive setups.
Option
Name
Description
[0]
Factory setup
Cannot be edited, but it is useful as a data source to return the other setups to a known state.
[1]*
Set-up 1
[1] Set-up 1 to [4] Set-up 4 can be edited freely during operation, independently of the active setup.
[2]
Set-up 2
[3]
Set-up 3
[4]
Set-up 4
[9]
Active Set-up
Can also be edited during operation. Edit the selected setup from a range of sources: LCP, FC RS485, FC
USB, or up to 5 fieldbus sites.
AU275636650261en-000101 / 130R033438 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide

Danfoss VLT HVAC Drive FC 102 Specifications

General

Enclosure	IP20, IP21, IP55
Ambient Temperature Range	-10°C to +40°C
Storage Temperature Range	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Communication Protocols	Modbus RTU, BACnet, Profibus
Certifications	CE, UL, cUL
Control Principle	PWM
Cooling Method	Forced air cooling
Input Voltage	200-240V, 380-480V, 525-600V
Control Modes	sensorless vector control, closed loop vector control
