Danfoss VLT HVAC Drive FC 102 Programming Guide

Parameter 16-31 System Temp.
Table 849: Parameter 16-31 System Temp.
16-31 System Temp.
Default value: 0 °C
Parameter type: Range, -128 - 127 °C
Setup: All setups
Conversion index: 100
Data type: Int8
Change during operation: True
Shows the highest internal system temperature. In the smaller enclosure sizes (A–C), the system temperature matches the control
card temperature measurement in parameter 16-39 Control Card Temp. In the larger enclosure sizes (D–F), the system temperature is
the highest temperature measured on hardware components with temperature sensors, for example, the power card(s).
Parameter 16-32 Brake Energy /s
Table 850: Parameter 16-32 Brake Energy /s
16-32 Brake Energy /s
Default value: 0 kW
Parameter type: Range, 0 - 10000 kW
Setup: All setups
Conversion index: 0
Data type: Uint32
Change during operation: False
View the brake power transmitted to an external brake resistor, stated as an instant value.
Parameter 16-33 Brake Energy Average
Table 851: Parameter 16-33 Brake Energy Average
16-33 Brake Energy Average
Default value: 0 kW
Parameter type: Range, 0 - 10000 kW
Setup: All setups
Conversion index: 0
Data type: Uint32
Change during operation: False
View the brake power transmitted to an external brake resistor. The mean power is calculated on an average level based on the
selected time period within parameter 2-13 Brake Power Monitoring.
Parameter 16-34 Heatsink Temp.
Table 852: Parameter 16-34 Heatsink Temp.
16-34 Heatsink Temp.
Default value: 0 °C
Parameter type: Range, 0 - 255 °C
Setup: All setups
Conversion index: 100
Data type: Uint8
Change during operation: False
View the drive heat sink temperature. The cutout limit is 90 ±5 °C (194 ±9 °F), and the motor cuts back in at 60 ±5 °C (140 ±9 °F).
Parameter 16-35 Inverter Thermal
Table 853: Parameter 16-35 Inverter Thermal
16-35 Inverter Thermal
Default value: 0%
Parameter type: Range, 0 - 100%
Setup: All setups
Conversion index: 0
Data type: Uint8
Change during operation: False
View the percentage load on the inverter.
AU275636650261en-000101 / 130R0334502 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide

Danfoss VLT HVAC Drive FC 102 Specifications

General

Enclosure	IP20, IP21, IP55
Ambient Temperature Range	-10°C to +40°C
Storage Temperature Range	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Communication Protocols	Modbus RTU, BACnet, Profibus
Certifications	CE, UL, cUL
Control Principle	PWM
Cooling Method	Forced air cooling
Input Voltage	200-240V, 380-480V, 525-600V
Control Modes	sensorless vector control, closed loop vector control
