Danfoss VLT HVAC Drive FC 102 Programming Guide

Select the output mode of analog terminal X49/1.
Option
Name
Description
[0]
Current
[1]*
Voltage
[2]
PT1000 [°C]
[3]
PT1000 [°F]
[4]
Ni 1000 [°C]
[5]
Ni 1000 [°F]
Parameter 36-01 Term. X49/3 Mode
Table 1304: Parameter 36-01 Term. X49/3 Mode
36-01 Term. X49/3 Mode
Default value: [1] Voltage
Parameter type: Option
Setup: All setups
Conversion index: -
Data type: Uint8
Change during operation: True
Select the output mode of analog terminal X49/3.
Option
Name
Description
[0]
Current
[1]*
Voltage
[2]
PT1000 [°C]
[3]
PT1000 [°F]
[4]
Ni 1000 [°C]
[5]
Ni 1000 [°F]
Parameter 36-02 Term. X49/5 Mode
Table 1305: Parameter 36-02 Term. X49/5 Mode
36-02 Term. X49/5 Mode
Default value: [1] Voltage
Parameter type: Option
Setup: All setups
Conversion index: -
Data type: Uint8
Change during operation: True
Select the output mode of analog terminal X49/5.
Option
Name
Description
[0]
Current
[1]*
Voltage
[2]
PT1000 [°C]
[3]
PT1000 [°F]
[4]
Ni 1000 [°C]
[5]
Ni 1000 [°F]
AU275636650261en-000101 / 130R0334 | 637Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide

Danfoss VLT HVAC Drive FC 102 Specifications

General

Enclosure	IP20, IP21, IP55
Ambient Temperature Range	-10°C to +40°C
Storage Temperature Range	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Communication Protocols	Modbus RTU, BACnet, Profibus
Certifications	CE, UL, cUL
Control Principle	PWM
Cooling Method	Forced air cooling
Input Voltage	200-240V, 380-480V, 525-600V
Control Modes	sensorless vector control, closed loop vector control
