Parameter 36-30 Terminal X49/5 Low Voltage
Table 1323: Parameter 36-30 Terminal X49/5 Low Voltage
36-30 Terminal X49/5 Low Voltage
Default value: 0.07 V
Parameter type: Range, 0 - 10 V
Setup: All setups
Conversion index: 0
Data type: Int16
Change during operation: True
Parameter 36-31 Terminal X49/3 Low Current
Table 1324: Parameter 36-31 Terminal X49/3 Low Current
36-31 Terminal X49/3 Low Current
Default value: 4 mA
Parameter type: Range, 0 - 20 mA
Setup: All setups
Conversion index: -3
Data type: Int16
Change during operation: True
Parameter 36-32 Terminal X49/5 High Voltage
Table 1325: Parameter 36-32 Terminal X49/5 High Voltage
36-32 Terminal X49/5 High Voltage
Default value: 10 V
Parameter type: Range, 0 - 10 V
Setup: All setups
Conversion index: 0
Data type: Int16
Change during operation: True
Parameter 36-33 Terminal X49/5 High Current
Table 1326: Parameter 36-33 Terminal X49/5 High Current
36-33 Terminal X49/5 High Current
Default value: 20 mA
Parameter type: Range, 0 - 20 mA
Setup: All setups
Conversion index: -3
Data type: Int16
Change during operation: True
Parameter 36-34 Terminal X49/5 Low Ref./Feedb. Value
Table 1327: Parameter 36-34 Terminal X49/5 Low Ref./Feedb. Value
36-34 Terminal X49/5 Low Ref./Feedb. Value
Default value: 0 ReferenceFeedbackUnit
Parameter type: Range, -999999.999 - 999999.999
ReferenceFeedbackUnit
Setup: All setups
Conversion index: 0
Data type: Int32
Change during operation: True
Parameter 36-35 Terminal X49/5 High Ref./Feedb. Value
Table 1328: Parameter 36-35 Terminal X49/5 High Ref./Feedb. Value
36-35 Terminal X49/5 High Ref./Feedb. Value
Default value: 100 ReferenceFeedbackU-
nit
Parameter type: Range, -999999.999 - 999999.999
ReferenceFeedbackUnit
Setup: All setups
Conversion index: 0
Data type: Int32
Change during operation: True
Parameter 36-36 Term. X49/5 Filter Time Constant
Table 1329: Parameter 36-36 Term. X49/5 Filter Time Constant
36-36 Term. X49/5 Filter Time Constant
Default value: 0.001 s
Parameter type: Range, 0.001 - 10 s
Setup: All setups
Conversion index: 0
Data type: Uint16
Change during operation: True
