Danfoss VLT HVAC Drive FC 102 Programming Guide

Option
Name
Description
[113]
PID clamped out-
put
[117]
Shaft power
[119]
Torque % lim
[123]
Speed both dir
[135]
Torq.% nom 4–
20mA
The torque setting is related to the motor torque setting.
[139]
Bus ctrl
An output value set from fieldbus process data. The output works independently of internal func-
tions in the drive.
[141]
Bus ctrl t.o.
Parameter 4-54 Warning Reference Low defines the behavior of the analog output in case of field-
bus timeout.
[147]
Main act val
[158]
Motor Volt.
Parameter 36-41 Terminal X49/7 Digital Output
Table 1331: Parameter 36-41 Terminal X49/7 Digital Output
36-41 Terminal X49/7 Digital Output
Default value: [0] No operation
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]*
No operation
[1]
Control ready
[2]
Drive ready
[3]
Drive rdy/rem ctrl
[4]
Enable/no warning
[5]
Running
[6]
Running/no warning
[7]
Run in range/no warn
[8]
Run on ref/no warn
[9]
Alarm
[10]
Alarm or warning
[11]
At torque limit
[12]
Out of current range
[13]
Below current, low
[14]
Above current, high
AU275636650261en-000101 / 130R0334644 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide

Danfoss VLT HVAC Drive FC 102 Specifications

General

Enclosure	IP20, IP21, IP55
Ambient Temperature Range	-10°C to +40°C
Storage Temperature Range	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Communication Protocols	Modbus RTU, BACnet, Profibus
Certifications	CE, UL, cUL
Control Principle	PWM
Cooling Method	Forced air cooling
Input Voltage	200-240V, 380-480V, 525-600V
Control Modes	sensorless vector control, closed loop vector control
