Danfoss VLT HVAC Drive FC 102 Programming Guide

Option
Name
Description
[80]
SL digital output A
[81]
SL digital output B
[82]
SL digital output C
[83]
SL digital output D
[84]
SL digital output E
[85]
SL digital output F
[90]
kWh counter pulse
[96]
Reverse after ramp
[98]
Virtual master dir
[120]
Local ref active
[121]
Remote ref active
[122]
No alarm
[123]
Start command activ
[124]
Running reverse
[125]
Drive in hand mode
[126]
Drive in auto mode
[151]
ATEX ETR cur. alarm
[152]
ATEX ETR freq. alarm
[153]
ATEX ETR cur. warning
[154]
ATEX ETR freq. warning
[173]
10Wh counter pulse
[180]
Clock fault
[181]
Prev. Maintenance
[188]
AHF Capacitor Connect
[189]
External Fan Control
[190]
Safe Function active
[191]
Safe Opt. Reset req.
[192]
RS Flipflop 0
[193]
RS Flipflop 1
[194]
RS Flipflop 2
[195]
RS Flipflop 3
[196]
RS Flipflop 4
AU275636650261en-000101 / 130R0334 | 653Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide

Danfoss VLT HVAC Drive FC 102 Specifications

General

Enclosure	IP20, IP21, IP55
Ambient Temperature Range	-10°C to +40°C
Storage Temperature Range	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Communication Protocols	Modbus RTU, BACnet, Profibus
Certifications	CE, UL, cUL
Control Principle	PWM
Cooling Method	Forced air cooling
Input Voltage	200-240V, 380-480V, 525-600V
Control Modes	sensorless vector control, closed loop vector control
