Danfoss VLT MCD 600 User Manual

Parameter group number
Parameter group name
Default setting
6-18
Motor Thermistor Circuit
Soft Trip and Log
6-19
Shorted SCR Action
3-Phase Control Only
6-20
Battery/Clock
Soft Trip and Log
7
Inputs
7-1
Input A Function
Input Trip (N/O)
7-2
Input A Trip
Operating Only
7-3
Input A Trip Delay
00:00 (mm:ss)
7-4
Input A Initial Delay
00:00 (mm:ss)
7-5
Input B Function
Input Trip (N/O)
7-6
Input B Trip
Operating Only
7-7
Input B Trip Delay
00:00 (mm:ss)
7-8
Input B Initial Delay
00:00 (mm:ss)
7-9
Reset/Enable Logic
Normally Closed (N/C)
7-10
Input A Name
Input A Trip
7-11
Input B Name
Input B Trip
8
Relay Outputs
8-1
Relay A Function
Run
8-2
Relay A On Delay
00:00 (mm:ss)
8-3
Relay A Off Delay
00:00 (mm:ss)
8-4
Relay B Function
Run
8-5
Relay B On Delay
00:00 (mm:ss)
8-6
Relay B Off Delay
00:00 (mm:ss)
8-7
Low Current Flag
50%
8-8
High Current Flag
100%
8-9
Motor Temperature Flag
80%
8-10
Main Contactor Time
400 ms
9
Analog Output
9-1
Analog Output A
Current (% FLC)
9-2
Analog A Scale
4–20 mA
9-3
Analog A Maximum Adjustment
100%
9-4
Analog A Minimum Adjustment
000%
10
Display
AQ262141844215en-000401 / 175R117478 | Danfoss A/S © 2020.12
Programmable Parameters
VLT® Soft Starter MCD 600
Operating Guide
