Danfoss VLT MCD 600 User Manual

Option
Function
DC Brake
Soft Brake
Table 66: 3-12 - Stop Time-2
Range
Function
*0 s
0:00–4:00 (mi-
nutes:seconds)
Sets the time for soft stopping the motor using TVR or adaptive control. If a main contactor is instal-
led, the contactor must remain closed until the end of the stop time. Use the main contactor output
(13, 14) to control the main contactor.
Table 67: 3-13 - Adaptive Stop Profile-2
Option
Function
Selects which profile the soft starter uses for an adaptive control soft stop.
Early Deceleration
*
Constant Deceleration
Late Deceleration
Table 68: 3-14 - Adaptive Control Gain-2
Range
Function
*75%
1–200%
Adjusts the performance of adaptive control.
This setting affects both starting and stopping control.
Table 69: 3-15 - Multi Pump-2
Option
Function
Adjusts the performance of adaptive control to suit installations with multiple pumps connected to a com-
mon outlet manifold.
*
Single Pump
Manifold Pump
Table 70: 3-16 - Start Delay-2
Range
Function
* 0 s
0:00–60:00 (minutes:seconds)
Sets a delay after the starter receives a start command before it starts the motor.
Table 71: 3-17 - DC Brake Torque-2
Range
Function
*20%
20–100%
Sets the amount of brake torque the soft starter uses to slow the motor.
Table 72: 3-18 - DC Brake Time-2
Range
Function
*1 s
0:01–0:30 (minutes:seconds)
Sets the duration for DC injection during a braking stop.
AQ262141844215en-000401 / 175R117488 | Danfoss A/S © 2020.12
Programmable Parameters
VLT® Soft Starter MCD 600
Operating Guide
