Danfoss VLT Micro Drive Programming Guide

13-01 Start Event
Option: Function:
[36] DigitalInput_29 Use value of DI 29 in logic rule.
[38] DigitalInput_33
[39] * StartCommand
This event is True, if frequency
converter is started by any means
(digital input or other).
[40] DriveStopped
This event is True, if frequency
converter is stopped or coasted by
any means (digital input or other).
13-02 Stop Event
Option: Function:
Select input to activate Smart Logic
Control.
[0] False
Enters False in logic rule.
[1] True
Enters True in logic rule.
[2] Running
See parameter group 5-4* Relays [5]
for description.
[3] InRange
See parameter group 5-4* Relays [7]
for description.
[4] OnReference
See parameter group 5-4* Relays [8]
for description.
[7] Out of Current
Range
See parameter group 5-4* Relays [12]
for description.
[8] BelowILow
See parameter group 5-4* Relays [13]
for description.
[9] AboveIHigh
See parameter group 5-4* Relays [14]
for description.
[16] ThermalWarning
See parameter group 5-4* Relays [21]
for description.
[17] MainsOutOfRange Mains voltage is outside the
specified voltage range.
[18] Reversing
See parameter group 5-4* Relays [25]
for description.
[19] Warning A warning is active.
[20] Alarm_Trip A trip alarm is active.
[21] Alarm_TripLock A trip lock alarm is active.
[22] Comparator 0 Use result of comparator 0 in logic
rule.
[23] Comparator 1 Use result of comparator 1 in logic
rule.
[24] Comparator 2 Use result of comparator 2 in logic
rule.
[25] Comparator 3 Use result of comparator 3 in logic
rule.
[26] LogicRule 0 Use result of logic rule 0 in logic
rule.
[27] LogicRule 1 Use result of logic rule 1 in logic
rule.
[28] LogicRule 2 Use result of logic rule 2 in logic
rule.
[29] LogicRule 3 Use result of logic rule 3 in logic
rule.
[30] SL Timeout0 Use result of timer 0 in logic rule.
13-02 Stop Event
Option: Function:
[31] SL Timeout1 Use result of timer 1 in logic rule.
[32] SL Timeout2 Use result of timer 2 in logic rule.
[33] DigitalInput_18 Use value of DI 18 in logic rule.
[34] DigitalInput_19 Use value of DI 19 in logic rule.
[35] DigitalInput_27 Use value of DI 27 in logic rule.
[36] DigitalInput_29 Use value of DI 29 in logic rule.
[38] DigitalInput_33
[39] StartCommand
This event is True, if frequency
converter is started by any means
(digital input or other).
[40] * DriveStopped
This event is True, if frequency
converter is stopped or coasted by
any means (digital input or other).
13-03 Reset SLC
Option: Function:
[0] * Do Not Reset Retains all settings programmed in
parameter group 13.
[1] Reset SLC Reset all group 13 parameters to default
settings.
4.10.3 13-04 Comparators
Comparators are used for comparing continuous variables
(i.e. output frequency, output current, analog input etc.) to
fixed preset values.
Par. 13-11
Comparator Operator
=
TRUE longer than.
. . .
. . .
Par. 13-10
Comparator Operand
Par. 13-12
Comparator Value
130BD022.10
Illustration 4.11
In addition, there are digital values that will be compared
to fixed time values. See explanation in 13-10 Comparator
Operand. Comparators are evaluated once in each scan
interval. Use the result (TRUE or FALSE) directly. All
parameters in this parameter group are array parameters
with index 0 to 5. Select index 0 toprogramme Comparator
0, select index 1 to programme Comparator 1, and so on.
13-10 Comparator Operand
Array [4]
Option: Function:
Select variable to be monitored by
comparator.
[0] * Disabled Comparator is disabled.
[1] Reference Resulting remote reference (not local) as a
percentage.
Parameter Descriptions
VLT
®
Micro Drive FC 51 Programming Guide
MG02C602 - VLT
®
is a registered Danfoss trademark 41
4 4
