Danfoss VLT Micro Drive Programming Guide

5.1.11 6-** Analog In/Out
Parameter
Number
Parameter Description Default Value 2 Setup
Change During
Operation
Conversi
on Index
Type
6-00 Live Zero Timeout Time 10 s All set-ups TRUE 0 Uint8
6-01 Live Zero TimeoutFunction [0] Off All set-ups TRUE - Uint8
6-10 Terminal 53 Low Voltage 0.07 V All set-ups TRUE -2 Uint16
6-11 Terminal 53 High Voltage 10 V All set-ups TRUE -2 Uint16
6-12 Terminal 53 Low Current 0.14 mA All set-ups TRUE -2 Uint16
6-13 Terminal 53 High Current 20 mA All set-ups TRUE -2 Uint16
6-14
Terminal 53 Low Ref./Feedb.
Value 0 All set-ups TRUE -3 Int32
6-15
Terminal 53 High Ref./Feedb.
Value 50 All set-ups TRUE -3 Int32
6-16 Terminal 53 Filter Time Constant 0.01 s All set-ups TRUE -2 Uint16
6-19 Terminal 53 mode [0] Voltage mode 1 set-up TRUE - Uint8
6-22 Terminal 60 Low Current 0.14 mA All set-ups TRUE -2 Uint16
6-23 Terminal 60 High Current 20 mA All set-ups TRUE -2 Uint16
6-24
Terminal 60 Low Ref./Feedb.
Value 0 All set-ups TRUE -3 Int32
6-25
Terminal 60 High Ref./Feedb.
Value 50 All set-ups TRUE -3 Int32
6-26 Terminal 60 Filter Time Constant 0.01 s All set-ups TRUE -2 Uint16
6-80 LCP Potmeter Enable 1 1 set-up FALSE - Uint8
6-81 LCP potentiometer Low Ref. 0 All set-ups TRUE -3 Int32
6-82 LCP potentiometer High Ref. 50 All set-ups TRUE -3 Int32
6-90 Terminal 42 Mode [0] 0-20 mA All set-ups TRUE - Uint8
6-91 Terminal 42 Analog Output [0] No operation All set-ups TRUE - Uint8
6-92 Terminal 42 Digital Output [0] No operation All set-ups TRUE - Uint8
6-93 Terminal 42 Output Min Scale 0% All set-ups TRUE -2 Uint16
6-94 Terminal 42 Output Max Scale 100% All set-ups TRUE -2 Uint16
Table 5.14
5.1.12
7-** Controllers
Parameter
Number
Parameter Description Default Value 2 Setup
Change During
Operation
Conversi
on Index
Type
7-20 Process CL Feedback 1 Resource [0] No function All set-ups TRUE - Uint8
7-30
Process PI Normal/ Inverse
Control [0] Normal All set-ups TRUE - Uint8
7-31 Process PI Anti Windup [1] Enabled All set-ups TRUE - Uint8
7-32 Process PI Start Speed 0 Hz All set-ups TRUE -1 Uint16
7-33 Process PI Proportional Gain 0.01 All set-ups TRUE -2 Uint16
7-34 Process PI Integral Time 9999 s All set-ups TRUE -2 Uint32
7-38 Process PI Feed Forward Factor 0% All set-ups TRUE 0 Uint16
7-39 On Reference Bandwidth 5% All set-ups TRUE 0 Uint8
Table 5.15
Parameter Lists
VLT
®
Micro Drive FC 51 Programming Guide
MG02C602 - VLT
®
is a registered Danfoss trademark 59
5 5

Danfoss VLT Micro Drive Specifications

General

Enclosure	IP20
Input Voltage	200-240V AC
Communication	Modbus RTU
Output Voltage	0-Input Voltage
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Relative Humidity	5-95% (non-condensing)
Altitude	Up to 1000m above sea level
