13-40 Logic Rule Boolean 1
Array [4]
Option: Function:
[9] AboveIHigh
See parameter group 5-4* Relays [14]
for description.
[16] ThermalWarning
See parameter group 5-4* Relays [21]
for description.
[17] MainsOutOfRange Mains voltage is outside the specified
voltage range.
[18] Reversing
See parameter group 5-4* Relays [25]
for description.
[19] Warning A warning is active.
[20] Alarm_Trip A trip alarm is active.
[21] Alarm_TripLock A trip lock alarm is active.
[22] Comparator 0 Use result of comparator 0 in logic
rule.
[23] Comparator 1 Use result of comparator 1 in logic
rule.
[24] Comparator 2 Use result of comparator 2 in logic
rule.
[25] Comparator 3 Use result of comparator 3 in logic
rule.
[26] LogicRule 0 Use result of logic rule 0 in logic rule.
[27] LogicRule 1 Use result of logic rule 1 in logic rule.
[28] LogicRule 2 Use result of logic rule 2 in logic rule.
[29] LogicRule 3 Use result of logic rule 3 in logic rule.
[30] SL Timeout0 Use result of timer 0 in logic rule.
[31] SL Timeout1 Use result of timer 1 in logic rule.
[32] SL Timeout2 Use result of timer 2 in logic rule.
[33] DigitalInput_18 Use value of DI 18 in logic rule.
[34] DigitalInput_19 Use value of DI 19 in logic rule.
[35] DigitalInput_27 Use value of DI 27 in logic rule.
[36] DigitalInput_29 Use value of DI 29 in logic rule.
[38] DigitalInput_33 Use value of DI 33 in logic rule
[39] StartCommand
This event is True, if frequency
converter is started by any means
(digital input or other).
[40] DriveStopped
This event is True, if frequency
converter is stopped or coasted by
any means (digital input or other).
13-41 Logic Rule Operator 1
Array [4]
Option: Function:
Select first logical operator to use on boolean
inputs from 13-40 Logic Rule Boolean 1 and
13-42 Logic Rule Boolean 2.
[0] * Disabled
Ignores 13-42 Logic Rule Boolean 2, 13-43 Logic
Rule Operator 2 and 13-44 Logic Rule Boolean
3.
[1] And Evaluates expression [13-40] AND [13-42].
[2] Or Evaluates expression [13-40] OR [13-42].
[3] And not Evaluates expression [13-40] AND NOT [13-42].
[4] Or not Evaluates expression [13-40] OR NOT [13-42].
[5] Not and Evaluates expression NOT [13-40] and [13-42].
13-41 Logic Rule Operator 1
Array [4]
Option: Function:
[6] Not or Evaluates expression NOT [13-40] OR [13-42].
[7] Not and not Evaluates expression NOT [13-40] AND NOT
[13-42].
[8] Not or not Evaluates expression NOT [13-40] OR NOT
[13-42].
13-42 Logic Rule Boolean 2
Array [4]
Option: Function:
Select second boolean input for selected logic rule.
See 13-40 Logic Rule Boolean 1 for choices and
descriptions.
13-43 Logic Rule Operator 2
Array [4]
Option: Function:
Select second logical operator to use on
boolean inputs calculated in 13-40 Logic Rule
Boolean 1, 13-41 Logic Rule Operator 1, and
13-42 Logic Rule Boolean 2 and the boolean
input from 13-42 Logic Rule Boolean 2.
[0] * Disabled
Ignores 13-44 Logic Rule Boolean 3.
[1] And Evaluates expression [13-40/13-42] AND
[13-44].
[2] Or Evaluates expression [13-40/13-42] OR [13-44].
[3] And not Evaluates expression [13-40/13-42] AND NOT
[13-44].
[4] Or not Evaluates expression [13-40/13-42] OR NOT
[13-44].
[5] Not and Evaluates expression NOT [13-40/13-42] and
[13-44].
[6] Not or Evaluates expression NOT [13-40/13-42] OR
[13-44].
[7] Not and not Evaluates expression NOT [13-40/13-42] AND
NOT [13-44].
[8] Not or not Evaluates expression NOT [13-40/13-42] OR
NOT [13-44].
13-44 Logic Rule Boolean 3
Array [4]
Option: Function:
Select third boolean input for selected logic rule.
See 13-40 Logic Rule Boolean 1 for choices and
descriptions.
