Danfoss VLT Midi Drive FC 280 Programming Guide

8-43 PCD Read Conguration
Enter up to 16 dierent preset mapping 0–15 in this parameter,
using array programming. If this parameter is active, addresses
2910–2925 represent values of the 16 parameters. If this
parameter is not active, addresses 2910 and 2911 are used as
status word register and main actual value. Addresses 2912–2925
are reserved.
Option: Function:
[25] [1661] Terminal 53 Switch
Setting
[26] [1662] Analog Input 53(V)
[27] [1663] Terminal 54 Switch
Setting
[28] [1664] Analog Input 54
[29] [1665] Analog Output 42 [mA]
[30] [1671] Relay Output [bin]
[31] [1672] Counter A
[32] [1673] Counter B
[33] [1690] Alarm Word
[34] [1692] Warning Word
[35] [1694] Ext. Status Word
8-50 Coasting Select
Option: Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
[0] Digital
input
Activates start command via a digital input.
[1] Bus Activates start command via the serial
communication port or eldbus option.
[2] Logic AND Activates start command via the eldbus/serial
communication port and 1 extra digital input.
[3] * Logic OR Activates start command via the eldbus/serial
communication port or via 1 of the digital
inputs.
8-51 Quick Stop Select
Select control of the quick stop function via the terminals (digital
input) and/or via the bus.
Option: Function:
[0] Digital input
[1] Bus
[2] Logic AND
[3] * Logic OR
[0] Digital input
[1] Bus
[2] Logic AND
[3] * Logic OR
8-52 DC Brake Select
Option: Function:
Select control of the DC brake via the terminals
(digital input) and/or via the eldbus.
NOTICE
When parameter 1-10 Motor Construction
is set to [1] PM non-salient SPM, only
selection [0] Digital input is available.
[0] Digital
input
Activates start command via a digital input.
[1] Bus Activates start command via the serial communi-
cation port or eldbus option.
[2] Logic
AND
Activates start command via the eldbus/serial
communication port and additionally via 1 of the
digital inputs.
[3] * Logic OR Activates start command via the eldbus/serial
communication port or via 1 of the digital
inputs.
8-53 Start Select
Option: Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the eldbus.
[0] Digital
input
Activates a start command via a digital input.
[1] Bus Activates a start command via the serial
communication port or eldbus option.
[2] Logic
AND
Activates a start command via the eldbus/
serial communication port and also via 1 of the
digital inputs.
[3] * Logic OR Activates a start command via the eldbus/
serial communication port or via 1 of the digital
inputs.
8-54 Reversing Select
Option: Function:
[0] Digital
input
Select control of the frequency converter reverse
function via the terminals (digital input) and/or
via the eldbus.
[1] Bus Activates the reverse command via the serial
communication port or eldbus option.
[2] Logic AND Activates the reverse command via the eldbus/
serial communication port and also via 1 of the
digital inputs.
[3] Logic OR Activates the reverse command via the eldbus/
serial communication port or via 1 of the digital
inputs.
Parameter Descriptions
VLT
®
Midi Drive FC 280
72 Danfoss A/S © 12/2015 All rights reserved. MG07C102
