4.2 Parameters: 1-** Load and Motor
1-00 Conguration Mode
Option: Function:
Select the application control principle to be
used when a remote reference (that is, analog
input or eldbus) is active.
[0]
*
Open Loop Enables speed control (without feedback
signal from motor) with automatic slip
compensation for almost constant speed at
varying loads. Compensations are active, but
can be disabled in parameter group 1-0* Load
and Motor. The speed control parameters are
set in parameter group 7-0* Speed PID Control.
[1] Speed
closed loop
Enables speed closed-loop control with
feedback. For increased speed accuracy,
provide a feedback signal and set the speed
PID control. The speed control parameters are
set in parameter group 7-0* Speed PID Control.
[2] Torque
closed loop
Enables torque closed-loop control with speed
feedback. Only possible when option [1] VVC
+
is selected in parameter 1-01 Motor Control
Principle.
[3] Process
Closed
Loop
Enables the use of process control in the
frequency converter. The process control
parameters are set in parameter groups 7-2*
Process Ctrl. Feedback and 7-3* Process PID Ctrl.
[4] Torque
open loop
[7] Extended
PID Speed
OL
1-01 Motor Control Principle
Option: Function:
[0] U/f
NOTICE
When running U/f, control slip and load
compensations are not included.
Used for parallel-connected motors and/or special
motor applications. Set the U/f settings in
parameter 1-55 U/f Characteristic - U and
parameter 1-56 U/f Characteristic - F.
[1] * VVC+
NOTICE
When parameter 1-10 Motor Construction is
set to PM-enabled options, only VVC
+
option
is available.
Normal running mode, including slip and load
compensations.
1-03 Torque Characteristics
Option: Function:
Select the torque characteristic
required. VT and AEO are both
energy-saving operations.
[0] * Constant torque
[1] Variable Torque
[2] Auto Energy Optim. CT
1-06 Clockwise Direction
Option: Function:
NOTICE
This parameter cannot be adjusted while
the motor is running.
This parameter denes the term clockwise
corresponding to the LCP direction arrow. Used for
easy change of direction of shaft rotation without
swapping motor wires.
[0] * Normal The motor shaft turns in clockwise direction when
frequency converter is connected U⇒U; V⇒V; and
W⇒W to motor.
[1] Inverse The motor shaft turns in counterclockwise
direction when frequency converter is connected
U⇒U; V⇒V; and W⇒W to motor.
1-08 Motor Control Bandwidth
Option: Function:
[0] High Suitable for high dynamic response.
[1] Medium Suitable for smooth steady-state operation.
[2] Low Suitable for smooth steady-state operation with
lowest dynamic response.
[3] Adaptive 1 Optimized for smooth steady-state operation,
with extra active damping.
[4] Adaptive 2 Focuses on low-inductance PM motors. This
option is an alternative to [3] Adaptive 1.
1-10 Motor Construction
Option: Function:
[0] * Asynchron For asynchronous motors.
[1] PM, non-
salient SPM
For permanent magnet (PM) motors with
surface-mounted (non-salient) magnets.
Refer to parameter 1-14 Damping Gain to
parameter 1-17 Voltage lter time const. for
details about optimizing the motor
operation.
[2] PM, salient
IPM, non Sat.
For permanent magnet (PM) motors with
interior (salient) magnets, without
inductance saturation control.
[3] PM, salient
IPM, Sat.
For permanent magnet (PM) motors with
interior (salient) magnets, with inductance
saturation control.
Parameter Descriptions Programming Guide
MG07C102 Danfoss A/S © 12/2015 All rights reserved. 31
4 4
