4.9 Parameters: 8-** Communications and
Options
8-01 Control Site
Option: Function:
The setting in this parameter overrides
the settings in parameter 8-50 Coasting
Select to parameter 8-56 Preset Reference
Select.
[0] * Digital and
ctrl.word
Control by using both digital input and
control word.
[1] Digital only Control by using digital inputs only.
[2] Controlword
only
Control by using control word only.
8-02 Control Source
Option: Function:
Select the source of the control word.
NOTICE
This parameter cannot be adjusted while
the motor is running.
[0] None
[1] FC Port
[2] FC USB
[3] Option A
8-03 Control Timeout Time
Range: Function:
1 s* [0.1 -
6000 s]
Enter the maximum time expected to pass
between the reception of 2 consecutive
telegrams. If this time is exceeded, it indicates
that the serial communication has stopped. The
function that is selected in
parameter 8-04 Control Timeout Function is then
carried out.
8-04 Control Timeout Function
Option: Function:
[0] * O Select the timeout function. The timeout
function is activated when the control word
fails to be updated within the time period
specied in parameter 8-03 Control Timeout
Time.
[1] Freeze output
[2] Stop
[3] Jogging
[4] Max. speed
[5] Stop and trip
8-07 Diagnosis Trigger
Option: Function:
[0] * Disable
[1] Trigger on alarms
[2] Trigger alarm/warn.
8-10 Control Word Prole
Select the interpretation of the control and status words
corresponding to the installed eldbus. Only the selections valid
for the installed eldbus are visible in the LCP display.
Option: Function:
[0] * FC prole
[1] PROFIdrive prole
[7] CANopen DSP 402
8-14 Congurable Control Word CTW
Option: Function:
[0] None
[1] * Prole default
[2] CTW Valid, active low
[4] PID error inverse
[5] PID reset I part
[6] PID enable
8-19 Product Code
Range: Function:
Size
related*
[0 -
2147483647]
Select 0 to read out the actual
eldbus product code according
to the mounted eldbus option.
Select 1 to read out the actual
vendor ID.
8-30 Protocol
Option: Function:
Select the protocol for the integrated RS485
port.
[0] * FC Communication according to the FC protocol.
[2] Modbus RTU Communication according to the Modbus
RTU protocol.
8-31 Address
Range: Function:
1* [ 0.0 - 247 ] Enter the address for the RS485 port. Valid
range: 1–126 for FC-bus, or 1–247 for Modbus.
8-32 Baud Rate
Option: Function:
Select the baud rate for the RS485 port.
[0] 2400 Baud
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
Parameter Descriptions
VLT
®
Midi Drive FC 280
70 Danfoss A/S © 12/2015 All rights reserved. MG07C102
