Dascom 2610 - Parts Description

Tally Dascom 2610
4
1.4 Parts description
1
Control Panel
LED: The 2-line LED with 4 keys panel indicates the
operating status and allows simple settings of the printer;
LCD: A LCD display and two keys indicates the operating
status and allows simple settings of the printer.
2
Latch
Sliding it down unfolds the cut sheet support.
3
Front Cover
Unlocking the front cover unfolds the cut sheets support.
4
Power Switch
Turns on and off the printer.
5
Hand Wheel
Turn the knob to load or clear the paper. It should be
inserted the full way until you can hears some sort of
“Click”.
6
Paper Support
At slanted position, it stacks cut sheets; at flat position, it
separates fanfold printouts from incoming forms.
7
Top Covers 1&2
Protect the internal parts and reduce the noise.
8
Head Gap Lever
Adjusts the gap between the print head and various
form thickness.
9
Paper Path Lever
Selects various paper sources.
10
Upper Friction
Guides the form when cut sheets or fanfold forms are used.
11
Power Socket
A power cord is plugged into the socket to supply the
power.
12
Interfaces
The interface cable of the host computer is plugged into
one of the interfaces.
13
Mute Cover Latch
You must open it before you open the top cover 1.
14
Print Head
Utilizes 24 needles to strike on ink ribbon and paper.
15
Ribbon Cartridge
Holds the ink ribbon fabric.
16
Tractors
Holds and transports fanfold forms.
17
Paper Guides
Left/Right
Sliding the guides varies the form width and the left
margin on a cut sheet.
18
Cut Sheet Support
A flat surface supports a sheet or multi-part form.
