Press Menu button to advance to the next menu
20- MON. SCHEDULE
Press Select button to display the current setting
MON: SETBACK/UP
SETBACK/UP or ON/OFF
Press Select button to change the setting from
setback/up to on/off. Default setting is
setback/up.
Press Menu button to go to the next setting. Use
Select button to set the start time for occupied
period. Default value is “N/C” (no change), this
means the unit will run in occupied mode all the
time. The time is set with 15 minutes increment.
OCCUPIED: XX:XX N/C
(NO CHANGE): 00:00 TO 23:45
Press Menu button to go to the next setting. Use
Select button to set the start time for unoccupied
period. Default value is “N/C” (no change), this
means the unit will run in occupied mode all the
time. The time is set with 15 minutes increment
UNOCCUPIED: XX:XX N/C
(NO CHANGE): 00:00 TO 23:45
All the day schedules in menus 20
through 26 are set in the same manner.
The Mini-DAP operates normally during
all periods designated as occupied.
During unoccupied periods, the Mini-
DAP operates in one of two ways,
depending on which type of schedule is
selected:
SETUP/SETBACK OPERATION
During unoccupied periods of a
SETBACK-UP schedule, the Mini-DAP II
will operate normally, except that it will
adjust its temperature and humidity
setpoint according to the values set in
menus 16 through 19. Operation of the
fan is TO BE SPECIFIED on menu #43.
ON/OFF OPERATION
During unoccupied periods of an
ON/OFF schedule, the Mini-DAP will
deactivate all heating, cooling,
humidification and dehumidification, and
the fan will remain off.
Press Menu button to advance to the next menu
21-TUE SCHEDULE
Similar in all respects to MON SCHEDULE.
Press Menu button to advance to the next menu
22-WED SCHEDULE
Similar in all respects to MON SCHEDULE.
Press Menu button to advance to the next menu
23-THU SCHEDULE
Similar in all respects to MON SCHEDULE.
Press Menu button to advance to the next menu
24-FRI SCHEDULE
Similar in all respects to MON SCHEDULE.
Press Menu button to advance to the next menu
25-SAT SCHEDULE
Similar in all respects to MON SCHEDULE.
Press Menu button to advance to the next menu
26-SUN SCHEDULE
Similar in all respects to MON SCHEDULE.
Press Menu button to advance to the next menu
EXIT THE MENU
Press Select button twice to exit to normal
operation. Otherwise press Menu button to go to
the next menu
27- TEMP SCALE
Press Select button to choose either F or C
temperature scale. Default setting is F scale
Press Menu button to advance to the next menu
28- TEMP DEADBAND
Press Select button to change the setting from
1°F to 5°F. default setting is 2°F.
Press Menu button to advance to the next menu
29- HI TEMP LIMIT
Press Select button to cycle the setting of the
high temperature alarm limit from 50°F to 90°F
in 1°F increments or Hi Temp Lim Disab.
Default setting is 80°F.
Press Menu button to advance to the next menu
30- LO TEMP LIMIT
Press Select button to cycle the setting of the
low temperature alarm limit from 50°F to 90°F in
1°F increments or Lo Temp Lim Disab.
Default setting is 60°F.
Press Menu button to advance to the next menu
31- CALIB TEMP
Press Select button to display the current
temperature with default 0 calibration offset.
TEMP+ 0.0 = xx
Press Select button to change the temperature
offset to make temperature reading matches a
reference temperature reading. The offset value
cycles from –20 to +20, default value is 0.0
Press Menu button to advance to the next menu
32- HUM DEADBAND
Press Select button to change the setting from
1% to 10%. Default setting is 3%
Press Menu button to advance to the next menu
33- HI HUM LIM
Press Select button to cycle the setting of the
high humidity alarm limit from 10% to 90% in 1%
increments or Hi Hum Lim Disab. Default setting
is 60%
