REV 8/03
24
Specifications
Power Requirements
24 VAC ± 10% @ 50/60 Hz
Current Draw
600 mA with no load
Control Output signal
24 VAC ± 10%
Alarm Input signal
24 VAC ± 10%
Fuse for Power supply F1
1 Amps, 5X20 mm fast- acting miniature fuse
Fuse for relay output F2
5 Amps, 5X20 mm fast- acting miniature fuse
Optional Remote Contact
rating
2A @ 30 VDC, .6 A @ 125 VAC (resistive)
Measuring Temperature
range
0°- 192 °F ± 1°F accuracy (89°C ± 1°C accuracy)
Measuring Relative Humidity
range
1% to 90% RH (± 3%) non-condensing
Temperature setpoint
60°F to 80°F, ± 1°F to ± 5°F deadband
Humidity setpoint
30% to 70%, ± 1% to ± 15% deadband
Connections
Miniature screw-type terminals
Wiring
22-18 AWG wires
Dimensions (H x W x D)
4 ¾ in. x 9 ¾ in. x 1 ¾ in. (120 x 248 x 44 mm)
Shipping Weight
1.75 lbs (800g )
PARTS LIST
PART NUMBER
MINI-DAP II PANEL 160-200-145
OPTIONAL REMOTE ALARM CONTACT 160-200-140
TEMPERATURE SENSOR 160-200-060
HUMIDITY SENSOR 160-200-202
