Emboss
The Emboss options let you specify values when using an embossingsystem.
1. Enter a value (within the allowable range) in the Current Value column.
 RegistrationXDist—The distance at which the card is registered at home inside of the
embosser. Select from -100 to 100 motor steps.
 TopperDwell—The length of time (dwell) in which the topping module applies topping
foil to the embossed characters. Select from 100 to 2000 milliseconds.
 TopperTemperature—The temperature, in degrees Celsius, at which the topping module
applies topping foil to the embossed characters. Select from 0 to 127 degrees C.
2. Click Set Current to apply the changes.
Description Default Value
Current Value
(unit) Allowed Range
1) RegistrationXDist 0 0 [-100 – 100]
2) TopperDwell 850 850 [100 – 2000]
3) TopperTemperature 121 121 [0 – 127]
