DataCard CE870

CE870 Instant Issuance System Installation and Administrator’s Guide 43
Finish Setup
After you have defined your system settings in Printer Manager, complete the setup of your
system.
Load Cards
 Cards can stick together. Slide or fan the cards to separate the edges before placing them in
the input hopper. Handle cards by their edges only.
 Insert ISO magnetic stripe cards with the stripe (back side) facing down and to the right.
 Insert smart cards with the smart card chip facing up and toward the back of the hopper.
Single-Hopper System
1. Unlock the printer and open the input hopper.
2. Remove and store any remaining blank test card stock.
3. Load cards into the input hopper.
4. Close the input hopper and lock the printer when you
finish loading cards.
A diagram inside the input hopper shows the correct orientation for each type of card.
