DataCard CE870

CE870 Instant Issuance System Installation and Administrator’s Guide 5
Clearance Requirements
The following measurements show the system dimensions when the system access doors are
open.
Single-Hopper System
Multi-Hopper System
We recommend that you provide a minimum of 3 inches (76.2 mm) of additional
clearance around the system to maintain access to the power cords and data cables,
to load and remove cards and supplies, and to provide ventilation for the system.
28 in
712 mm
24.4 in
620 mm
24 in
609 mm
24.7 in
628 mm
38 in
962 mm
27 in
686 mm
23.4 in
595 mm
