20 Installation
2. Press the silver latch button and open the
printer swingarm.
3. Prepare the print ribbon cartridge.
a. Remove the print ribbon cartridge from the
printer.
b. Locate the cleaning roller spindle and
slide the spindle into the cleaning
sleeve (a).
c. Place the spindle with cleaning sleeve
onto the ribbon cartridge (b).
d. Remove the protective wrapper from
the cleaning sleeve (c).
Load the print ribbon on printers that have the optional printhead installed.
Refer to “Load the Print Ribbon (Optional)” on page 21 for details.
Print Ribbon
Cartridge
Protective
Wrapper
Cleaning Roller
Spindle
To Next Page
