CR500 Instant Issuance System Quick Install Guide
English
f. Loadtheretransferlmcartridge
Donotreturntheretransferlm
cartridge until after the cleaning card
is run.
5. Run the Cleaning Card
Do not run the cleaning card if the
heat roller is hot. Allow the printer to
coolrst.
a. Close the Print Unit door.
e. Removethegreenretransferlm
cartridge.
b. Keep the Security Enclosure
cover open.
c. Slide the Exception Slide out.
d. Insert the cleaning card.
i. Remove the protective paper
from the cleaning card (A).
ii. Insert the cleaning card into
the Exception slide with the
sticky side facing up. Push
it in until the end of the card
rests in the slot (B).
iii. Push the Exception Slide in,
past the resistance until it
reaches the stop position (C).
iv. Push the card to the Print
Unit card feed roller (D). Stop
when the card is just under
the roller (E).
A
B
2 frames
D
A
B
Film Guides Supply Roll
C
