SD260L/SD360/SD460 Installation and Administrator’s Guide A-3
Clearance Requirements
The following measurements show the system dimensions when the input hopper, printer cover,
and laminator access doors are open.
SD460 Electrical Requirements
The power supply is rated as follows:
We recommend that you provide a minimum of 3 inches (76.2 mm) of additional
clearance around the system to maintain access to the power cord and data cables,
to load and remove cards and supplies, and to provide ventilation.
System Component
Electrical Requirements
Input Output
Printer 110–240V/50–60 Hz/1.5 Amp 24V/3.0Amp/72W
Laminator with L1 only 100–240V/47–63 Hz/2.2 Amp 24V/3.75Amp/90W
Laminator with L1, L2,
and impresser
100–240V/47–63 Hz/2.2 Amp 24V/6.6Amp/160W
9.0 in
229 mm
25.5 in
648 mm
23.6 in
600 mm
26.1 in / 663 mm
29.5 in / 749 mm
(with impresser)
11.4 in
290 mm
19.6 in
498 mm
3.1 in
79 mm
