SD260L/SD360/SD460 Installation and Administrator’s Guide 9
Install Optional Equipment
You can install additional equipment on the printer depending on your requirements.
Install a Large Output Hopper
The output hopper included with the printer holds about 25 0.030 in. (0.762 mm) cards. The
printer also can be used with an optional large output hopper that holds up to 100 cards.
The large output hopper kit includes two base sections and the large output hopper. The two
base sections are identical, with hooks (marked by green circles) that attach to the bottom of the
printer. To assemble the base, arrange the base sections back to back, as shown.
You can remove the standard hopper and attach the large output hopper without using tools.
You cannot install the large output hopper on the SD460 system. A 100-card
laminator output hopper is standard on the SD460 system.
Base Sections
Large Output
Hopper
Standard Output
Hopper
To Next Page
