6-42 Removal and Replacement
Cable Replacement Procedure
 Some of the cables described below are optional and may not be present on
all printers.
1. With the printer laying on its side and the control board placed next to it,
begin connecting the cables that will reach.
A. Magnetic stripe registration sensor
B. Magnetic stripe optical encoder cable (disconnect the other end from the
encoder)
C. Duplex interface cable (disconnect the other end from the duplex module)
D. Printhead power
E. RFID antenna
F. Magnetic stripe head
2. Tilt the printer up at an angle and continue to make connections.
A. Smart card contact cable
B. Smart card solenoid
C. Printhead data
D. Printhead cam sensor
3. Set the printer on top of the control board and make the last connections.
A. Transport motor
B. Printhead fan
C. Pick/Ribbon motors
D. Cam motor
E. Ribbon index sensor
F. Ribbon motion
G. Card input sensor
H. Swingarm up sensor
I. LCD display
4. With the card tray and duplex assemblies attached, press the transport into
the interstage platform.
• Verify that all cable connectors are properly seated, even if they were not
disconnected.
• Refer to the Print Engine Front Wire Routing Diagram and Print Engine Cable
Connection Diagram for replacement details.
• Print several test cards to verify that the printer is functioning properly.
