Start Sentinel/End Sentinel
The specific data on a card is bracketed by a Start Sentinel and an End Sentinel.
These are used to identify where valid data begins and ends. These two sentinels
are reserved characters and cannot be used for any other reason on the magnetic
stripe. For this reason, the sentinel characters will not be standard letters or
numeric characters. (Just like any other character written to the card, the
sentinel’s binary word also includes a parity bit.)
Longitudinal Redundancy Check (LRC)
This is a final parity check for the entire data string. Unlike the parity bit
mentioned in the preceding section, the LRC is a complete binary word itself,
with the same number of bits as the specific data characters.
Each bit in the LRC binary word (except its own parity bit) represents a single
parity check for all of the preceding bits in the same position. This can best be
explained by examining the binary data in the tabular form shown below. Each
character’s parity bit makes the horizontal sum
of bits an odd number. The LRC
makes the vertical sum
of all the individual bits an even number. (The LRC’s
own parity bit sets the parity for the LRC word in the same manner as it would
for any other character.)
Binary Char Code
Name
Parity
Bit
2
5
2
4
2
3
2
2
2
1
2
0
Bit
Sum
Char
Start Sentinel 1 0
0
0 1
0
1
3 %
Sample Data 1 0
1
0 1
1
1
5 7
Sample Data 0 1
0
0 0
1
1
3 C
Field Separator
0 1
1
1 1
1
0
5 ^
Sample Data 1 1
1
0 0
1
1
5 S
Sample Data 1 1
1
1 0
1
0
5 Z
End Sentinel 0 0
1
1 1
1
1
5 ?
Pre-LRC Sum
4
5
3 4
6
5
LRC
0 0
1
1 0
0
1
3
Post-LRC Sum
4
6
4 4
6
6
