3. Pressthecartridgereleasebuttonandpulloutthefilmcartridge.Thecartridgemaybe
difficulttopulloutifthecardisstucktothelaminatefilm.Pulloutthecartridgeslowlyto
avoiddroppingthelaminatefilmfromthecartridge.Ifthecartridgecannotberemoved,call
for
service.
4. Removethejogdialfromthecardprinterandattachittothejogdialinsertionslot.
5. Turnthejogdialcounterclockwisetodischargethe
cardfromthecardoutlet.
6. Inspectthecartridge:
 Ifthematerialonthecartridgeisinonepiece:
 Turnthebottom‐sidecartridgetak e‐upknobcounter‐
clockwiseuntilalldamagedmaterialiswoundneatlyon
thetake‐upspool.
 Turnthetop‐sidecartridgetak e‐upknobclockwiseuntil
allthedamagedmaterialiswoundneatlyonthetake‐up
spool.
 Ifthematerialissplitorbroken:
 Trimtheendsofthebrokenportionsevenly.
 Aligntheendofthesupplymaterialwiththetak e‐up
spoolandapplytapetosecureit.
 Turnthematerialontothetak e‐upspooluntilthe
mendedportioniswoundtwoorthreeturns.
7. Replacetheloadedlaminatorcartridgeintheprinteruntilit
clicksintoposition.
8. Closethelaminatordoor.Thelaminatorreinitializesautomatically.
Supply Roll
Take-up Spool
Tape
