Loading Retransfer Film
1. Slidethedoorlatchupandopentheprinterdoor(1).
2. Presstheretransferfilmreleasebuttonandremovethe
greencartridge(2).
3. Removebothusedfilmspoolsfromthecartridge(if
present).
4. Loadthenewrollofretransferfilmonthecartridge:
a. Putthefullrolloffilmon
thegreensupplyspindle
(A).
b. Puttheemptytake‐upspoolontheblacktake‐up
spindle(B).
c. Alignfilmalongthethreefilmguides.
d. Windtwoframesoffilmontothetak e‐upspool
(D).Setthefilmsothatablackframelineis
positionednexttothefilm
guide,asshownonthelabelinsidethecartridge.
e. Takeupanyslackbyturningthetake‐upknob
clockwise.Gentlypullthetake‐upknobandturn.
Ifslackcannotberemoved,verifythatthesupply
andtake‐upspoolsarefirmlyseatedonthe
spindles.
Toeaseinsertinginto
theprinter,thefilmmust
betightalongthefilmguides.Turningthesupply
andtake‐upknobshelpsmaintaintheproper
tension.
5. Replacetheloadedfilmcartridgeintheprinteruntilit
clicksintoposition(5).
6. Closetheprinterdoor(6).
Theretransferfilmcartridgecannotbeloadedifthe
printerisintransportmode.Powerontheprinter
untilitdisplaysanerror,andthenpoweritoffagain
tocanceltransportmode,ifnecessary.
1
2
E
6
5
