Introduction to this User Manual 1.
This User manual has been developed for PLC programmers who intend to connect a
Datalogic Laser Marker to a PLC via ProfiNet/IO, in order to handle the Laser Marker and
its operations following the flow of the Production Chain.
All the screenshots and tests made as a reference for the creation of this User Manual
were made using the following versions of HW and SW:
Element used
Versioning
PLC
Siemens S7-1200
CPU 1214C DC/DC/DC
Article no. 6ES7 214-1AG31-0XB0
Firmware rev. 3.0
PLC programming SW tool
TIA Portal v.13 SP1
Datalogic Laser Marker
Arex430
Lighter version
Lighter 7.2.0 Alpha 8
Datalogic S.r.l. recommends to read this User Manual carefully before
performing any kind of operation both on the PLC and the Laser Marker. I case of any
doubts, please contact your local Datalogic Technical Support or fill in the Support
Webform on the Datalogic s.r.l website at the following link.
