Datalogic DS4600A User Manual

DS4600A
3
DS4600A-200X (Medium Range)
4
2
0
-2
10
8
6
-4
-6
(in)
02 64 12
(in)
810 141618
0
50
100
150 200 250 300 350 400 450 500 550
(mm)
250
200
150
100
50
0
-50
-100
-150
-200
-250
(mm)
20 22
0.25 mm
(10 mils)
0.30 mm
(12 mils)
0.50 mm
(20 mils)
-8
-10
NOTE: (0,0) is the center of the laser beam output window
CONDITIONS:
Test Codes used = Interleaved 2/5 and Code 39
"Pitch" angle = 0
°
"Skew" angle = 15
°
"Tilt" angle = 0
°
Code Resolution* = High for 0.30 mm (12 mils) codes and smaller
Standard for 0.50 mm (20 mils) codes and greater
Code Reading Cond.* = Standard
* Parameter selectable in WinHost
32

Datalogic DS4600A Specifications
