DATA FORMAT
PRODUCT REFERENCE GUIDE 283
Label ID: Set Individually Per Symbology — continued
Table 16 Label ID Examples
STEP ACTION EXAMPLES
1 Scan the ENTER/EXIT bar code (Reader enters Programming Mode)
2
Determine placement of the
Label ID
characters BEFORE
or AFTER with regard to
scanned data using Label ID
Control, starting on page 87
Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix
3
Scan the bar code selecting
t
he symbology type you wish
to designate label ID charac-
ters for using Label ID Sym-
bology Selection, starting on
page 88
GS1 DataBar
Omnidirectional
Code 39 Interleaved 2 of 5 Code 32
4
Custom Label ID example
(desir
ed characters):
D B * = C 3 + PH
5
Find hex equivalents from the
ASCI
I table (inside back cover),
then scan in these digits/char-
acters using the bar codes in
th
e section: Keypad, starting
on page 328. f you make a
mistake before the last char-
acter, scan the CANCEL bar
code to abort and not sav
e the
entry string. You can then start
again at the beginning.
44 42 2A 3D 43 33 2B 50 48
6 Scan the ENTER/EXIT bar code
(Reader exits Label ID entry)
7
Scan the ENTER/EXIT bar code
once
again
(Reader exits Programming Mode)
Result:
DB*[bar code data]
[bar code data]=C3
+[bar code data]
[bar code data]PH
