GRYPHON™ I GD/GBT/GM4500
USING THE GBT/GM4500 READER
Reader LEDs
Specific LEDs on the Gryphon reader provide information about: good reading result
(3GL), battery status. The Battery Status information can be easily retrieved by double-
tapping with your fingers on top of the head of the reader. The following table explains
the main color combinations provided by the Battery Status LED.
Table 1 - Battery LED
50% - 99%
1% - 49%
Charge less than 1%
NOTE: Re
ader is unusable until 1% is reached
Charge 100%
NOTE: It goes OFF
when the reader is unplugged
50% - 100%
2% - 50%
Charge less than 2%
LED STATUS
Charge in Progress through micro USB
Green blinking
(1s ON - 1s OFF)
Amber blinking
(1s ON - 1s OFF)
Red blinking
(1s ON - 1s OFF)
Solid Green
Battery Status (when not in charge)
Green (3s time-out)
Amber (3s time-out)
Red (3s time-out)
