Datalogic GRYPHON BT100 - Gryphon BT Series Reading Performance; BT100 Standard Reading Zones; BT200 PDF Reading Zones

DATALOGIC
18
UK/US
GRYPHON™ BT SERIES
GRYPHON

 BT100 (STANDARD)
0 5 10 15 20 25 30 35
-15
-10
-5
0
5
10
15
M100 (STD) - Reading Zones (10° skew angle)
(cm)
CODE 39
0.13 mm
(5 mils)
EAN13 M=1
0.33 mm
(13 mils)
CODE 39
0.50 mm
(20 mils)
CODE 39
0.076 mm
(3 mils)
0.13 mm
(5 mils)
GRYPHON

 BT200 (PDF)
0 5 10 15 20 25 30 35
-10
-5
0
5
10
M200 (PDF) - Reading Zones (10° skew angle)
(cm)
CODE39
0.076 mm
(3 mils)
CODE39
0.13 mm
(5 mils)
EAN13 M=1
0.33 mm
(13 mils)
CODE39
0.50 mm
(20 mils)
0.13 mm
(5 mils)
0 2 4 6 8 10 12 14 16
-8
-6
-4
-2
0
2
4
6
8
(cm)
M200 (PDF) - PDF417 codes, Reading Zones (10° skew angle)
PDF417 Aspect Ratio 3:1
0.25 mm
(10mils)
0.17 mm
(6.6mils)
0.38 mm
(15mils)
