246 GRYPHON™ I GD/GBT/GM4200
STAR Radio Protocol Timeout
This parameter sets the valid wait time before transmission between the handheld
reader and Base Station is considered failed.
When setting this parameter, take into consideration the radio traffic (number of read-
ers in the same area). The selectable range for this feature is from 02 to 25 seconds.
Follow these instructions to set this feature:
1. Determine the desired setting.
2. Pad the number with leading zeroes to yield two digits. For example: 2 = 02, 5 =
0
5, 25 = 25, etc
3. Scan the ENTER/EXIT PROGRAMMING MODE barcode to enter Programming
Mo
de.
4. Scan the barcode: SELECT RADIO PROTOCOL TIMEOUT.
5. Scan the appropriate two digits from the keypad in
Appendix D, that represent the
duration which was determined in the steps above. You will hear a two-beep indi-
cation after the last character.
6. Scan the ENTER/EXIT PROGRAMMING MODE barcode to exit Programming Mode.
This completes the procedure. See Table 29 for so
me examples of how to set this fea-
ture.
Table 23 STAR Radio Protocol Timeout Examples
NOTE: If you make a mistake before the last character, scan the CANCEL
bar code to abort and not save the entry string. You can then start again at
the beginning.
STEP
ACTION EXAMPLES
1 Desired Setting
No delimiter
character
, (comma) - (dash) / (slash)
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SET SOURCE RADIO ADDRESS DELIMITER CHARACTER
4
Scan two characters from
Appendix D
‘0’ and ‘0’ ‘2’ and ‘C’ ‘2’ and ‘D’ ‘2’ AND ‘F’
5 Scan ENTER/EXIT PROGRAMMING MODE
