PRODUCT REFERENCE GUIDE 251
APPENDIX A
TECHNICAL SPECIFICATIONS
The table below contains Physical and Performance Characteristics, User Environment
and Regulatory information. Table 34 provides Standard Cable Pinouts.
GD4200 TECHNICAL SPECIFICATIONS
Table 26 GD4200 Technical Specifications
ELECTRICAL CHARACTERISTICS
Power Supply
GD4220: 5VDC ± 5%
GD4290: 4.5 - 14.0 VDC
Consumption
Operating (Typical): <350mA @ 5V <150mA @12V
Standby/Idle (Typical): <60mA @5V <30mA @12V
Max. Scan Rate 400 reads/sec
Reading Indicators Top and rear illumination, Good Read Spot, Beep
OPTICAL CHARACTERISTICS
Optical Format CCD solid state sensor (2500 pixels)
Illumination System
LED Source
Dual LED Array 612-630nm
Ambient Light Up to 130,000 lux
Tilt Tolerance
a
+/- 45°
Pitch Tolerance
a
+/- 65°
Skew Tolerance
a
+/- 65°
Field of View
a
HORIZONTAL 36° +/- 1°
PCS (Datalogic Test
Chart)
minimum 15%
