Setting Up the Reader
4 Gryphon™ I GM44XX
2. Using your thumbs, push open the plastic tabs on the
bottom of the base to free the wing holders.
Figure 3. Tabs
3. The stand can now be repositioned in either horizon-
tal or standing position.
Figure 4. Stand positions
Tab
Tab
Horizontal
Standing
