Technical Specifications
36 Gryphon™ I GM44XX
Depth of Field (Typical)
a
a 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A,
typical environmental light, 20°C, label inclination 10°
Symbology SR:
Code 39
5mil: 1.6” -7.5” (4.0 -19cm)
10mil: 0.4” - 11.8” (1.0 - 30cm)
20mil: up to 17.7” (up to 45cm)
EAN
7.5mil: 0.5” - 10.6” (2.0 - 27cm)
13mil: 0.6” - 15.7” (1.5 - 40cm)
PDF-417
6.6mil: 1.0” - 5.9” (2.5 - 15cm)
10mil: 0.2” - 8.6” (0.5 - 22cm)
15mil: 0.6” - 13.4” (1.5 - 34cm)
DataMatrix
10mil: 0.8” to 6.3” (2.0 - 16cm)
15mil: 0” to 9.3” (0 - 23.6cm)
QR Code
10mil: 1.2” to 4.9” (3.0 - 12.5cm)
15mil: 0.4” to 7.5” (1.0 - 19cm)
Minimum Element Width
Standard Range:
1D Min. Resolution = 4 mil
PDF-417 Min.Resolution = 5 mil
Datamatrix Min. Resolution = 7 mil
Print Contrast Minimum 25% minimum reflectance
