LED and Beeper Indications
40 Gryphon™ I GM44XX
a Except when in sleep mode or when a Good Read LED Duration other than 00 is selected
Programming Mode
- The following indications ONLY occur when the
reader is in Programming Mode.
Green Spot
a
flashes
momentarily
Upon successful read
of a label, the soft-
ware shall turn the
green spot on for the
time specified by the
configured value.
N/A N/A
Cap
t
ure
When ready to cap-
ture image
Blue light flashes
2 times when
updating
N/A
INDICATION DESCRIPTION LED BEEPER
Label Programming
Mode Entry
A valid programming
label has been
scanned.
LED blinks
cont
inu-
ously
Reader sounds
four low fre-
quency beeps.
Label Programming
Mode Rejection of
Label
A label has been
rejected.
N/A
Reader sounds
th
ree
times at
lowest frequency
and current vol-
ume.
Label Programming
Mode Acceptance of
Partial Label
In cases where multi-
ple labels must be
scanned to program
one feature, this indi-
cation acknowledges
each portion as it is
successfully scanned.
N/A
Reader sounds
one sh
ort beep
at
highest frequency
and current vol-
ume.
Label Programming
Mode Acceptance of
Programming
Configuration
option(s) have been
successfully pro-
grammed via labels
and the reader has
exited Programming
Mode.
N/A
Reader sounds
one h
i
gh fre-
quency beep and
4 low frequency
beeps followed by
reset beeps.
Indication Description LED Beeper
