10 Magellan™ 3500HSi
Programming
Upon completing the physical connection between the scanner and its
host, proceed directly to the Programming Bar Codes below to locate the
interface type the scanner is connected to (for example: RS-232, Key-
board Wedge, USB, etc.).
Use the Bar Code Mask at the back of this manual to isolate the bar code
you intend to scan. Scan a START/END bar code once to enter Program-
ming Mode. After scanning the programming label for the desired inter-
face, scan the START/END barcode a second time to accept your changes,
exit Programming Mode and return the scanner to normal operation.
You can select other options and customize your scanner through use of
the instructions and programming bar codes available in the PRG or use
the On Screen Programming (OSP) utility available from the website
listed on the back cover of this manual.
Interface Selection
START / END
PROGRAMMING BAR CODES
RS-232 Standard
RS-232 Wincor-Nixdorf
To Next Page
