TYPICAL LAYOUTS
93
6
When using a Local Area Network (LAN), one or more Matrix 210 21X-X1X can be
connected to the network by using CAB-ETH-M0x cables:
Figure 105 - Ethernet Network Layout
CBX
Matrix 210™
HOST
NETWORK
Power
CAB-ETH-M0x
CAB-MSxx
1
2
3
Ethernet Interface
Auxiliary Serial Interface (Local Echo) (RS232)
External Trigger (for One Shot or Phase Mode)
