2.6 MODEL DESCRIPTION
The Matrix 210™ reader is available in different versions according to the following
characteristics:
Illuminators
1 = Internal Illuminator
Focus Distance
1 = Near
2 = Medium
3 = Far
4 = UHD
Sensor Size
2 = WVGA (752x480)
Reading Window
0 = 90°
1 = Straight
Interface
0 = Serial
1 = Ethernet
2 = USB
Options
0 = Standard
1 = ESD Safe
2 = ESD Safe + YAG Cut Filters
2.7 ACCESSORIES
The following accessories can be used with the Matrix 210™ 21X-x0x and Matrix 210™ 21X-
x1x model readers.
Linear Array Lighting System
M12-IP67 Ethernet Cable (1M)
M12-IP67 Ethernet Cable (3M)
M12-IP67 Ethernet Cable (5M)
Backup Module for CBX100/500
Display Module for CBX500
Ethernet TCP/IP Module STD/IP65 for CBX500
Profibus Module STD/IP65 for CBX500
DeviceNet Module IP65 for CBX500
EtherNet/IP Module STD/IP65/IP54 for CBX500
93ACC1812, 93ACC1813,
93ACC1840
CAN Open Module for CBX500
Profinet IO Module for CBX500
CC-Link Module for CBX500
Modbus TCP Module STD/IP65 for CBX500
Quick Link Slave ID-NET + Service T-Connector
Quick Link Master ID-NET - Serial Host Connector
Quick Link Master ID-NET - Ethernet Host Connector
Quick Link Metal Master ID-NET - EtherNet/IP Gateway
Quick Link Metal Master ID-NET - Profibus Gateway
Quick Link Metal Master ID-NET - Profinet IO Gateway
