Parameters to verify/modify:
 Operating Mode
Sets the parameters which customize the reader operating mode
starting from three main modes:
One Shot: acquires a single image based on the selected value
for the Acquisition Trigger and Acquisition Trigger Delay.
Continuous: continuously acquires images with a rate up to the
maximum allowable frame rate per second for the given sensor
depending on the decoding time and the Region of Interest
settings.
Phase Mode: acquires images during the reading phase
depending on the selected value for the Acquisition Trigger and
Acquisition Trigger Delay. The Reading Phase-ON and Reading
Phase-OFF events mark respectively the beginning and end of
the reading phase.
 Calibration
Calibrates the acquisition parameters to maximize the reading
performance (see par. 8.4.3).
 Communication
Configures the parameters relative to each serial port regarding
the transmission, message formatting and string receiving.
Any change to the VisiSet™ communication port parameters
(baud rate, data bits, etc.) is effective as soon as the reader is
disconnected from VisiSet™.
 Reading System Layout
Allows configuring the device according to the desired layout:
Standalone, ID-NET™ or Master/Slave RS232
 WebSentinel
Enables the Ethernet WebSentinel Agent for communication with
the Datalogic WebSentinel™ plant array monitor.
 Ethernet
For (21x-x1x models) Sets the parameters related to the on-
board Ethernet interface and to its communication channels.
 CBX Gateway
Sets the parameters related to the External Host Interface
Module through the CBX500 and to its communication channels.
 Image Processing
Sets the image processing parameters shared by all available
symbologies.
 1D & 2D, Postal Codes
Sets the characteristics of the code symbologies to be read.
 Data Collection
Defines the code-collection parameters and the output message
format.
 Digital I/O
Configures the reader input/output parameters.
 Match Code
Allows setting a user-defined code and relative parameters to
which the read code will be compared (matched).
 Miscellaneous
Sets the reader name and the saved image format.
 Symbol Verification
Sets the parameters relative to the various specifications in the
Standards which regulate code validation.
 LEDs And Keypad
Sets the X-PRESS™ LED and Keypad parameters related to their
selected Functions: Beeper, Green Spot, Positioning, etc.
 Display
Sets the Display language and Layout of the BM150 Display
when using the CBX500 connection box.
 Diagnostics
Enables various diagnostic messages, formatting and actions.
When all the configuration parameters are set correctly, save them to the Matrix 210™
reader by pressing the Send button. See Figure 113.
